Turnkey-Solution

MVS6400-LV

MV Turnkey Solution for 1500 Vdc String Inverter SG350HX
Transformer type : Oil immersed
Max. power : 7040 kVA @ 30 ℃ - 6400 kVA @ 40 ℃
Maximum input current at nominal voltage : 2540 A * 2
Efficiency : ≥ 99 %
Cooling type : ONAN (Oil Natural Air Natural)
Approximate weight : 22 T

SG3425UD-MV - SG3600UD-MV

Turnkey Station for North America 1500 Vdc System - MV Transformer Integrated
Min. PV input voltage / Startup input voltage
875 V / 915 V         915 V / 955 V
AC output power
3425 kVA @ 45 ℃( 113 ℉ ),          3600 kVA @ 45℃( 113 ℉ )
3083 kVA @ 50 ℃( 122 ℉ )**            3240 kVA @ 50℃( 122 ℉ )**
No. of DC inputs : 20 ( optional: 22 / 24 / 26 / 28 )
Inverter Max. efficiency : 98.9 %
Weight : 18000 kg 39683.2 lbs

SG3125HV-MV-30

Turnkey Station for 1500 Vdc System MV Transformer Integrated
Min. PV input voltage / Startup input voltage : 875 V / 915 V
Max. PV input current : 3997 A
Max. inverter output current : 3308 A
Inverter max. efficiency : 99.0%
Weight : 15 T

SG3425UD-MV - SG3600UD-MV

Turnkey Station for North America 1500 Vdc System - MV Transformer Integrated
Min. PV input voltage / Startup input voltage
875 V / 915 V         915 V / 955 V
AC output power
3425 kVA @ 45 ℃( 113 ℉ ),         3600 kVA @ 45℃( 113 ℉
3083 kVA @ 50 ℃( 122 ℉ )**         3240 kVA @ 50℃( 122 ℉ )**
No. of DC inputs : 20 ( optional: 22 / 24 / 26 / 28 )
Inverter Max. efficiency : 98.9 %
Weight : 18000 kg 39683.2 lbs

MVS6400-LV

MV Turnkey Solution for 1500 Vdc String Inverter SG350HX
Transformer type : Oil immersed
Max. power : 7040 kVA @ 30 ℃ - 6400 kVA @ 40 ℃
Maximum input current at nominal voltage : 2540 A * 2
Efficiency : ≥ 99 %
Cooling type : ONAN (Oil Natural Air Natural)
Approximate weight : 22 T
